Hom |
GHL-10 |
GHL-50 |
GHL-150 |
GHL-200 |
GHL-250 |
GHL-300 |
GHL-400 |
GHL-600 |
|
Ntim (L) |
10 |
50 |
150 |
200 |
250 |
300 |
400 |
600 |
|
Peev xwm (kg / batch) |
3 |
15 |
50 |
80 |
100 |
130 |
200 |
300 |
|
Blending ceev (rpm) |
300/210 |
300/210 |
270/180 |
270/180 |
188/130 |
160/110 |
120/85 |
120/80 |
|
Lub zog sib xyaw (KW) |
1.5/2.2 |
4/5.5 |
9/11 |
11/14 |
11/14 |
11/14 |
15/17 |
22/30 |
|
Txiav fais fab (KW) |
0.85/1.1 |
1.5/2.2 |
2.4/3 |
3.3/4 |
3.3/4 |
4.5/5.5 |
6.5/8 |
9/11 |
|
Txiav ceev (rpm) |
1440/2900 |
|||||||
|
Lub sijhawm ua haujlwm (min) |
8-15 |
|||||||
|
Particle loj (mesh) |
20-80 |
|||||||
Feature:
1.Qhov sib tov ceev ceev granulator txais kab rov tav lub tog raj kheej qauv.Nws cov qauv tsim nyog.
2.Siv cua ntim cov ntsaws ruaj ruaj rau tsav. Thaum ntxuav, nws tuaj yeem hloov mus rau dej.
3.Fluidized Granulation thiab cov duab ntawm granule yog ze rau pob. Nws ntws zoo.
4.Piv nrog cov txheej txheem ib txwm muaj, 25% ntawm cov nplaum tuaj yeem txo qis thiab lub sijhawm ziab tuaj yeem luv.
5.Lub sij hawm sib tov qhuav yog 2 feeb thiab lub sij hawm ntawm granulating yog 1-4 feeb. Muab piv nrog cov txheej txheem ib txwm ua.
6.Nyob rau hauv tib lub ntim ntim, qhuav sib tov thiab granulating tuaj yeem ua tiav. Nws ua raws li cov kev cai ntawm GMP.
7.Qhov kev ua haujlwm tag nrho muaj kev nyab xeeb thiab kev tiv thaiv.
Daim ntawv thov:
Cov ntaub ntawv yog pub rau hauv lub lauj kaub granulating los ntawm lub tshuab nqus tsev feeder los yog nqa feeder. Tom qab qhov kev txiav txim ntawm centrifugal quab yuam ntawm kev sib tov paddle, lub siab ua kua system txhaj cov nplaum los ntawm rab phom tsuag. Lub caij no, lub cutter tig ntawm kev kub ceev. Cov ntaub ntawv raug khi rau hauv qhov khoob hauv lub lauj kaub thiab tawm mus rau cov txheej txheem tom ntej (granule sizing lossis ziab) tom qab granulating tiav.
